Model: LỌC KHÍ INGERSOLL RAND MODEL FA,IH (0.01 MICRON)
Bình chọn của bạn:
Air quality to ISO 8573.1:2010 / Class 1 Solid particulate / Class 1 oil
Particle removal down to 0.01 micron
Including water and oil aerosols
Maximum remaining oil aerosol content of 0,01 mg/m3 @ 21°C
Operating Limitations
Maximum operating pressure 17.2 bar (g)
Maximum operating temperature 80C
Minimum operating temperature 1C
Compliance with PED 97/23/EC and CE
Standard filters include differential gauge and 1/2″F Manual
|
Capacity |
PORT | Dimension |
Filter |
Quantity |
||||
| Model |
7 bar g |
CONN |
A |
B |
Weight |
Filter |
Element |
Per |
|
m³/min |
BSPT |
mm |
mm |
Kg |
CPN |
CPN |
Filter |
|
| FA30IH |
0.48 |
3/8″ |
76 |
172 |
0.562 |
24356511 |
24356693 |
1 |
| FA40IH |
0.62 |
1/2″ |
76 |
172 |
0.547 |
24231896 |
24241853 |
1 |
| FA75IH |
1.27 |
3/4″ |
98 |
227 |
1.069 |
24231987 |
24241903 |
1 |
| FA110IH |
1.84 |
3/4″ |
98 |
227 |
1.091 |
24232050 |
24241960 |
1 |
| FA150IH |
2.49 |
1″ |
129 |
266 |
2.063 |
24232134 |
24242034 |
1 |
| FA190IH |
3.12 |
1″ |
129 |
266 |
2.063 |
24232217 |
24242091 |
1 |
| FA230IH |
3.82 |
1″ |
129 |
266 |
2.063 |
24232290 |
24242166 |
1 |
| FA400IH |
6.66 |
1 1/2″ |
129 |
356 |
2.361 |
24232381 |
24242224 |
1 |
| FA490IH |
8.21 |
1 1/2″ |
129 |
356 |
2.361 |
24232464 |
24242273 |
1 |
| FA600IH |
9.91 |
2″ |
170 |
465 |
5.196 |
24232548 |
24242315 |
1 |
| FA800IH |
13.31 |
2″ |
170 |
465 |
5.238 |
24232621 |
24242356 |
1 |
| FA1000IH |
16.99 |
2″ |
170 |
465 |
5.257 |
24232704 |
24242398 |
1 |
| FA1200IH |
20.11 |
3″ |
205 |
547 |
9.307 |
24232787 |
24242430 |
1 |
| FA1560IH |
26.05 |
3″ |
205 |
647 |
10.694 |
24232860 |
24242471 |
1 |
| FA1830IH |
30.59 |
3″ |
205 |
647 |
10.694 |
24232944 |
24242513 |
1 |
| FA2300IH |
38.23 |
3″ |
205 |
877 |
13.696 |
24233025 |
24242554 |
1 |
| FA2700IH |
45.31 |
3″ |
205 |
877 |
13.696 |
24233108 |
24242596 |
1 |
Options and Parts
Options and Parts
|
O RING |
DIFFERENTIAL |
CLAMP |
BRACKET |
||
|
SET |
GAUGE(BSPT) |
KIT |
KIT |
||
| MODEL |
CPN |
CPN |
CPN |
CPN |
|
|
F30I |
24356701 |
24356750 |
24361917 |
24361966 |
|
|
F40I |
24334930 |
24356750 |
24361917 |
24361966 |
|
|
F75I-F110I |
24334955 |
24335044 |
24361925 |
24361974 |
|
|
F150I-F230I |
24334963 |
24335044 |
24361933 |
24361982 |
|
|
F400I-490I |
24334971 |
24335044 |
24361933 |
24361982 |
|
|
F600I-1000I |
24334989 |
24335044 |
24361941 |
24361990 |
|
|
F1200I |
24334997 |
24335044 |
24361958 |
24362006 |
|
|
F1560I-F1830I |
24335002 |
24335044 |
24361958 |
24362006 |
|
|
F2300I-F2700I |
24335010 |
24335044 |
24361958 |
24362006 |
|
|
24335028 |
AUTO DRAIN F.Series | ||||
|
24335036 |
MANUAL DRAIN F.Series | ||||
